BALL RUNNER BLOCK CARBON STEEL KWD-045-FLS-C1-N-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-045-FLS-C1-N-1 (R165341420) is a state-of-the-art ball runner block designed for precision linear movement and high-load applications. This product boasts a robust steel CS construction, ensuring durability and a long service life. It is characterized by size FLS, with a flange width, long length, and standard height, tailored for demanding rigidity requirements. This runner block operates with low preload (class C) and standard accuracy (class N), without the inclusion of a ball chain. It comes pre-lubricated with Dynalub grease for initial use and features preservation measures to maintain its integrity over time. The runner block's design includes straight lube connections that are loosely attached for ease of maintenance. Designed to be interchangeable, it can be combined with guide rails of every accuracy level, enhancing its versatility across various applications. The B.RUNNER BLOCK CS is engineered to reduce frictional oscillations and maintain low friction levels even under external load conditions. Its dynamic characteristics are optimized for maximum precision; the patented entry zone increases travel accuracy significantly. The product also offers long-term lubrication possibilities spanning several years thanks to metal-threaded lube fittings on all sides. Attachments can be mounted from both above and below the runner block, which also features integrated all-around sealing for protection against contaminants. The high torque load capacity coupled with different preload classes provides flexibility in application design. Moreover, this ball runner block is capable of improved rigidity under lift-off and side-loading conditions due to additional mounting screw holes at its center. It supports maximum system rigidity through a pre-tensioned O-arrangement and has the option to integrate an inductive, wear-free measuring system. Compatible with all SN/SNO ball guide rails, this Bosch Rexroth runner block offers uniform load ratings in all four main loading directions and comes factory pre-lubricated. It represents an ideal solution for linear motion systems requiring precision, durability, interchangeability, and versatile mounting options.
