BALL RUNNER BLOCK CARBON STEEL KWD-045-FLS-C0-N-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-045-FLS-C0-N-1 (R165349422) is a high-precision ball runner block designed for linear motion applications requiring maximum rigidity and dynamic performance. This runner block features an FLS format with a flanged width, long length, and standard height, constructed from unalloyed steel CS. It falls under preload class C, indicating that it is preload-free, and accuracy class N for standard accuracy levels. Equipped with a ball chain, the runner block facilitates low noise operation and optimal travel behavior. The B.RUNNER BLOCK CS KWD-045-FLS-C0-N-1 is characterized by its ability to handle demanding rigidity requirements while maintaining significantly reduced frictional oscillations and low friction force levels even under external load conditions. Its excellent dynamic characteristics are further enhanced by a patented entry zone that increases travel accuracy up to six times compared to other systems. The product also boasts long-term lubrication capabilities that can extend over several years, thanks to its initial factory lubrication and preservation. This model provides high torque load capacity across all four main loading directions due to its design that allows the use of just one runner block per rail if needed. The inclusion of two additional mounting screw holes at the center improves rigidity under lift-off and side loading conditions. For added versatility, it offers an end-face fastening thread for all attachments and integrated all-around sealing. Designed for interchangeability, the Bosch Rexroth B.RUNNER BLOCK CS can be combined with guide rails of every accuracy level. It supports optional features such as an integrated inductive measuring system without wear factors and allows attachment mounting from both above and below the runner block body. In summary, this Bosch Rexroth ball runner block is engineered for applications where precision movement, high load capacity, and long-term reliability are paramount. It stands out for its robust construction, advanced sealing options like SS (Standard seal), LS (Low-friction seal), DS (Double-lip seal), front seal options for various environmental challenges, FKM seal for extreme environments, cover plate wiper against coarse dirt or chips; all contributing to its suitability in diverse industrial settings where linear motion systems play a critical role.
