BALL RUNNER BLOCK CARBON STEEL KWC-055-FNS-C2-H-2

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWC-055-FNS-C2-H-2 (R165152310) is a high-precision ball runner block designed for use in linear guidance systems that demand high rigidity and load-bearing capacity. This runner block features a size FNS format, indicating a flange width, normal length, and standard height. It is constructed from unalloyed steel CS and offers medium preload (class C) alongside high accuracy (class H), without the inclusion of a ball chain. This product boasts an overall length of . mm and provides exceptional performance due to its design, which includes two additional mounting screw holes at the center for enhanced rigidity under liftoff and side loading conditions. The innovative channel design allows for minimal lubrication quantities, while the optimized ball return and guideway ensure smooth and quiet operation. The entry zone geometry is engineered to minimize variation in elastic deflection. The B.RUNNER BLOCK CS KWC-055-FNS-C2-H-2 is versatile with its ability to accommodate attachments from both above and below, providing flexibility for various mounting scenarios. It also features end-face fastening threads compatible with all attachments. Designed to be used with all SNS Ball Guide Rails, it offers limitless interchangeability among different guide rail versions. Furthermore, this runner block is self-aligning to compensate for misalignments without self-alignment capabilities. It has a dynamic load capacity C and can handle significant dynamic torsional moment loads (Mt). The product operates within an ambient temperature range of min ... max °C and maintains a low friction coefficient between . and . Its static load rating C0 ensures stability under stationary loads. In summary, the Bosch Rexroth B.RUNNER BLOCK CS KWC-055-FNS-C2-H-2 (R165152310) is an advanced component ideal for heavy-duty machine construction requiring maximum rigidity in all load directions with high torque load capacity. Its precision engineering ensures reliability in demanding applications where precise linear movement is critical.
