BALL RUNNER BLOCK CARBON STEEL KWC-055-SLH-C3-P-2

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWC-055-SLH-C3-P-2 (R162453210) is a high-precision ball runner block designed for linear motion systems that demand rigidity and accuracy. This runner block belongs to the SLH series, which features a slimline width, long length, and high height profile, tailored for applications where space is limited in the transverse direction but high rigidity is required. Constructed from unalloyed steel CS, the runner block has an overall length of . mm and offers a high preload class C, ensuring it can handle heavy loads with minimal deflection. Its precision accuracy class P signifies that it meets stringent dimensional tolerances for precise motion control. Notably, this model does not include a ball chain, initial lubrication, or attachment elements on either front reference edge. The B.RUNNER BLOCK CS KWC-055-SLH-C3-P-2 features angular lube nipples loosely attached to facilitate maintenance and lubrication. It's capable of enduring dynamic load capacities as per DIN ISO standards and can accommodate high torque load capacities. The low noise level during operation and exceptional travel behavior make it suitable for quiet environments or applications sensitive to acoustic disturbances. Designed for heavy machine construction with an extremely high load-bearing capacity, this runner block maintains the same high load ratings in all four main loading directions. It allows for long-term lubrication over several years without frequent maintenance. The product can be used with all SNS ball guide rails and offers flexibility with different preload classes available. Furthermore, the Bosch Rexroth runner block can be used in various ambient temperatures ranging from min ... max °C (for short durations). It also includes an end-face fastening thread for attachments that can be mounted from above the block itself. The product's robust design permits applications using just one runner block per rail when necessary due to its high rigidity in all load directions.
