BALL RUNNER BLOCK CARBON STEEL KWC-055-SLH-C0-H-2
Manufacturer: Bosch Rexroth
Material #: R162459310
Model : B.RUNNER BLOCK CS KWC-055-SLH-C0-H-2
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWC-055-SLH-C0-H-2 (R162459310) is a high-precision, heavy-duty ball runner block designed for use in various applications where space is limited and high rigidity is required. This model features a slimline width, long length, and high height format (SLH), with the runner block body crafted from unalloyed steel CS. It boasts a preload class C, indicating it is preload-free, and an accuracy class H for highly accurate operations.
The product does not include a ball chain and comes preserved without initial lubrication. It allows for easy attachment from above with endface fastening threads but does not include attachment elements on either the left or right front reference edges. Angular lube nipples are provided loosely attached for convenience.
With an overall length of . mm, this runner block can be combined with guide rails of every accuracy level, enhancing versatility in application. Its design enables it to withstand extremely high load-bearing capacities and torque loads while maintaining low noise levels and excellent travel behavior. The B.RUNNER BLOCK CS KWC-055-SLH-C0-H-2 supports long-term lubrication options that can last several years and offers the possibility of using various preload classes.
This model can be utilized on all SNS ball guide rails and is capable of handling high rigidity demands in all four main loading directions, which makes it suitable for applications that may require only one runner block per rail. The permissible ambient temperature range for this product extends from min ... max °C for short periods; however, consultation is recommended for operation at negative temperatures.
In terms of dynamic load capacity C and dynamic torsional moment load capacity Mt, the values are determined based on a 100 km travel as per DIN ISO . For comparison purposes or different stipulations of travel distance, the values from the table should be multiplied by .. The Bosch Rexroth B.RUNNER BLOCK CS KWC-055-SLH-C0-H-2 also features various seal options like SS standard seals or LS low-friction seals to prevent ingress of contaminants such as dirt or metal particles which could potentially reduce its service life.
$505.02 USD
More are expected on January 9, 2025
Status: This product is temporarily out of stock.
Qty: Delivered as early as January 9, 2025 when ordered in
