BALL RUNNER BLOCK CARBON STEEL KWC-055-SLS-C0-N-2
Manufacturer: Bosch Rexroth
Material #: R162359410
Model : B.RUNNER BLOCK CS KWC-055-SLS-C0-N-2
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWC-055-SLS-C0-N-2 (R162359410) is a high-precision ball runner block designed for applications requiring compact dimensions and high load-bearing capacity. This runner block is part of the Ball Rail Systems product group, offering a slimline width, long length, and standard height profile. The body of the runner block is constructed from unalloyed steel CS, ensuring durability and robustness in demanding environments.
Notable features include its preload class C, indicating that it is preload-free, and accuracy class N for standard precision. The B.RUNNER BLOCK CS KWC-055-SLS-C0-N-2 lacks a ball chain and comes without initial lubrication or attachment elements on either front reference edge. It includes angular lube nipples that are loosely attached to enable easy maintenance.
This model boasts a low noise level and exceptional travel behavior due to its design with four rows of balls allowing point contact in all loading directions. This minimizes friction and heat generation during operation. The runner block's seals protect against contaminants such as dirt, chips, and coolants, thus extending its service life. It comes with standard SS seals but can be fitted with alternative seals like LS (low-friction), DS (double-lip), or FKM for extreme environments upon servicing.
With high rigidity in all load directions, the B.RUNNER BLOCK CS KWC-055-SLS-C0-N-2 supports applications where only one runner block per rail may be necessary. It offers various mounting options through end-face fastening threads and can be used with all SNS Ball Guide Rails. Furthermore, the possibility of long-term lubrication over several years makes it an efficient choice for continuous use applications.
The Bosch Rexroth B.RUNNER BLOCK CS KWC-055-SLS-C0-N-2 (R162359410) represents a versatile solution for heavy machine construction where space is limited transversely but where heavy loads and high torque capacities are needed.
$480.99 USD
Availability: 1 In Stock
Available for immediate shipmentQty: Delivered as early as December 24, 2024 when ordered in
