R162359310

BALL RUNNER BLOCK CARBON STEEL KWC-055-SLS-C0-H-2

Manufacturer: Bosch Rexroth

Material #: R162359310

Model : B.RUNNER BLOCK CS KWC-055-SLS-C0-H-2


***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWC-055-SLS-C0-H-2 (R162359310) is a high-precision ball runner block designed for heavy-duty machine construction, capable of handling extremely high load-bearing capacities and torque loads. The product features a slimline width, long length, and standard height format (SLS), with the runner block body crafted from unalloyed steel CS. It offers high accuracy with its high-class precision and is preload-free (preload class C). This runner block operates quietly and has excellent travel behavior, with the same high load ratings in all four main loading directions. It is equipped with angular lube nipples loosely attached for easy maintenance and can be used on all SNS ball guide rails. The robust design allows for applications that require only one runner block per rail, simplifying system design. The B.RUNNER BLOCK CS KWC-055-SLS-C0-H-2 boasts a dynamic load capacity C and static torsional moment load capacity Mt, ensuring its suitability for applications that experience varied loads and moments. For added versatility, it features endface fastening threads for various attachments. The product does not come with an initial lubrication but is preserved for longevity; long-term lubrication options are available to extend service life over several years. Self-aligning capabilities allow for compensation of misalignments without the need for a ball chain. Its friction coefficient ensures minimal resistance to movement, contributing to its efficient operation. With a permissible ambient temperature range, this runner block maintains performance in diverse environmental conditions. Finally, the Bosch Rexroth B.RUNNER BLOCK CS KWC-055-SLS-C0-H-2 can be interchanged with guide rails of every accuracy level, making it a flexible choice for integration into existing systems or new installations requiring precise linear motion control.

$505.02 USD

More are expected on February 17, 2025
  Add to Cart

Status: This product is temporarily out of stock.


Qty: Delivered as early as February 17, 2025 when ordered in
