R162319320

BALL RUNNER BLOCK CARBON STEEL KWD-015-SLS-C0-H-1

Manufacturer: Bosch Rexroth

Material #: R162319320

Model : B.RUNNER BLOCK CS KWD-015-SLS-C0-H-1


***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-015-SLS-C0-H-1 (R162319320) is a high-precision ball runner block designed for linear motion applications requiring compact design and high load capacity. This runner block is part of the Ball Rail System, featuring a slimline width, long length, and standard height (SLS format) which makes it suitable for restricted spaces with transverse direction constraints. It is constructed from unalloyed steel CS and offers preload-free operation (preload class C) with high accuracy (class H), ensuring precise movement without initial tension. Notably, this model does not include a ball chain and comes with initial lubrication and preservation using Roller bearing grease Dynalub. It has been engineered to provide high torque load capacity, thanks to its optimized entry-zone geometry and numerous balls that minimize elastic deflection variation. The runner block allows for attachments to be mounted from above and features an integrated all-around sealing system. Additionally, it includes a minimum quantity lubrication system with an oil reservoir for long-term maintenance-free operation. The B.RUNNER BLOCK CS KWD-015-SLS-C0-H-1 can be used on all SN/SNO Ball Guide Rails, boasting excellent dynamic characteristics suitable for various applications. With its interchangeable design, it can be combined with guide rails of every accuracy level within its class. This runner block also offers a high dynamic load capacity as per DIN ISO standards, with the ability to withstand significant acceleration and torque loads. Furthermore, the product comes equipped with standard seals to prevent contamination from dirt or chips, enhancing its service life in challenging environments. Its overall length is . mm while maintaining interchangeability across different rail systems within each accuracy class. This Bosch Rexroth ball runner block is optimized for applications demanding reliable precision and durability in linear motion systems.

$188.58 USD

More are expected on August 23, 2024
  Add to Cart

Status: This product is temporarily out of stock.


Qty: Delivered as early as August 23, 2024 when ordered in
