BALL RUNNER BLOCK CARBON STEEL KWD-015-SLS-C2-H-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-015-SLS-C2-H-1 (R162312322) is a high-precision ball runner block designed for linear motion applications requiring compactness, high load capacity, and accuracy. This runner block features a slimline width, long length, and standard height (SLS format), made from unalloyed steel CS. It offers medium preload (preload class C) and high accuracy (accuracy class H), ensuring smooth motion and reduced variability in elastic deflection. The B.RUNNER BLOCK CS KWD-015-SLS-C2-H-1 is equipped with a ball chain to enhance travel behavior while keeping noise levels low. It comes pre-lubricated with Dynalub grease for initial use and has provisions for long-term lubrication to extend service intervals. The runner block's design allows for mounting attachments from above and includes an integrated all-around sealing system to protect against contaminants. Its dynamic characteristics are optimized by the geometry of the entry zone and the number of balls used. This model is capable of handling very high loads from all four main loading directions due to its robust construction. The interchangeability feature allows it to be combined with guide rails of every accuracy class within the Bosch Rexroth range, offering flexibility in system design. The B.RUNNER BLOCK CS KWD-015-SLS-C2-H-1 can be used on all SN/SNO ball guide rails, has an end-face fastening thread for various attachments, and features a minimum quantity lubrication system with an integrated oil reservoir. In terms of technical specifications, this runner block has an overall length of . mm and can withstand ambient temperatures ranging from min ... max °C for short periods. The dynamic load capacity C is determined based on a 100 km travel as per DIN ISO . For applications that require different preload classes or specific friction coefficients, this model offers versatility while maintaining its excellent dynamic properties and high torque capacity.
