R162261410

BALL RUNNER BLOCK CARBON STEEL KWC-065-SNS-C1-N-2

Manufacturer: Bosch Rexroth

Material #: R162261410

Model : B.RUNNER BLOCK CS KWC-065-SNS-C1-N-2


***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWC-065-SNS-C1-N-2 (R162261410) is a high-precision ball runner block designed for heavy-duty machine construction and applications where space is restricted in the transverse direction. This runner block boasts a slimline width, normal length, and standard height, with an unalloyed steel CS body. It features a low preload class C and standard accuracy class N, without the inclusion of a ball chain. Key capabilities of this product include its high load-bearing capacity, ability to withstand high torque loads, and uniform load ratings in all four main directions. It operates with low noise levels and provides excellent travel behavior. The B.RUNNER BLOCK CS is also notable for its rigidity in all load directions, which allows for the use of just one runner block per rail in certain applications. This model comes without initial lubrication but is preserved for long-term use and can be lubricated over several years. It offers end-face fastening threads for attachments and can be used interchangeably with guide rails of every accuracy level. The angular lube nipples are loosely attached to facilitate maintenance. The Bosch Rexroth B.RUNNER BLOCK CS KWC-065-SNS-C1-N-2 is self-aligning to compensate for misalignments and has been designed with various seals to prevent contamination from dirt, chips, or coolants, thus extending its service life. It supports different preload classes and features lube fittings with metal threads on all sides for ease of maintenance. In summary, this Bosch Rexroth ball runner block is a robust component suitable for demanding linear motion tasks where durability, precision, and versatility are required. Its design ensures reliable performance even in challenging industrial environments while offering flexibility in terms of maintenance and long-term operation.

$713.12 USD

Availability:  22  In Stock
  Add to Cart
Available for immediate shipment

Qty: Delivered as early as December 24, 2024 when ordered in
