CLAMPING ELEMENT MK 4505 AK ...

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth CLAMPING ELEMENT MK 4505 AK (R161944260) is a high-quality pneumatic clamping unit designed for integration with ball rail systems. This unit stands out for its ability to deliver high axial holding forces within a compact format, offering both dynamic and static stabilization in the axial direction. The simple mechanical gripping principle employed by the MK 4505 AK ensures an excellent price-performance ratio, making it an economical choice for a variety of applications. Capable of being mounted on all SNS ball guide rails, this clamping element is characterized by its chemically nickel-plated steel housing which contributes to high axial and horizontal rigidity. Precision positioning is made possible through the use of high-precision linear screw drives, enhancing both dynamics and drive power while ensuring an extended service life. The pressure can be continuously adjusted up to 8 bar, allowing for customizable clamping force depending on the specific requirements of the task at hand. Decompression is achieved through spring force facilitated by a preloaded return spring, enabling short decompression cycles that are essential for efficient operation. With a capability of enduring 1 million clamping cycles, this robust unit promises reliability and durability in performance. The MK 4505 AK operates within a permissible ambient temperature range of -10°C to +80°C and has been designed to consume minimal air—only approximately 2.4 liters per cycle at standard air port size E profiled rail systems. It accommodates various sizes of profiled rail systems including sizes A, B, E, H, N, and S with corresponding thread diameters for versatile application potential. In summary, the Bosch Rexroth CLAMPING ELEMENT MK 4505 AK is an effective solution for users requiring precise control over their pneumatic clamping needs in conjunction with ball rail systems across numerous applications.
