BRAKING ELEMENT KBH 4505 AS1A

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth KBH 4505 AS1A (R161944021) is a hydraulic braking element designed for precision and reliability in demanding applications. This braking unit is compatible with all SNS ball guide rails, ensuring versatility across various rail sizes including B, H, E, A, S, and N profiled rail systems. It boasts a robust construction with a solid steel housing that is chemically nickel-plated for durability and resistance to harsh conditions. The KBH 4505 AS1A operates efficiently with a hydraulic pressure of up to 250 bar for clamping and braking operations, while a pretensioned return spring facilitates rapid decompression cycles. This model is engineered to deliver high positioning accuracy and can endure up to 10 million clamping cycles and up to 250,000 emergency braking operations without compromising performance. The release pressure is set at 50 bar, which contributes to the safety and control of the system. An integrated all-around sealing coupled with special pressure diaphragm technology ensures maximum functional reliability by preventing pressure losses or leakage. The brake shoes feature integrated positive-locking with large-surface contact profiles that provide maximum axial rigidity, contributing to the unit's super heavy-duty capabilities. The KBH 4505 AS1A has been designed for low displacement volume during operation and supports a high holding force that maintains stability under load. Additionally, it has threaded connections on both sides for easy integration into hydraulic systems. With its compact design conforming to DIN standards, this braking element from Bosch Rexroth offers an exceptional solution for applications requiring precise motion control and significant holding power in automation and linear motion systems.
