BALL GUIDE RAIL CARBON STEEL KSA-015-SNS-U-MA-AB

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.GUIDE RAIL CS (R160516932) is a high-precision ball guide rail designed for demanding applications where rigidity and accuracy are paramount. This rail is part of the ball rail systems, featuring a slimline width, normal length, and standard height, making it suitable for a variety of configurations. It is constructed from carbon steel CS, ensuring durability and longevity even in harsh environments. The guide rail comes with an ultra-precision accuracy class and is equipped with a cover strip made from corrosion-resistant spring steel conforming to DIN EN standards. Additionally, it includes screw-down plastic protective caps with threaded holes on the end faces for added protection. The B.GUIDE RAIL CS offers maximum rigidity in all load directions and has an impressive torque load capacity. This model supports a two-piece rail configuration and allows for bolting from above using fastener MA. Its compact strip clamp design facilitates easy mounting while maintaining a clean aesthetic due to the single cover that conceals all holes. The product's dimensions include a size T profiled rail system with a nominal size that ensures compatibility with various setups. For those operating within specific temperature ranges, this guide rail can withstand ambient temperatures from minimum to maximum degrees Celsius but consult Bosch Rexroth for operations at negative temperatures. The maximum length of the rail (Lmax) can be tailored to meet the requirements of your application. The B.GUIDE RAIL CS boasts an impressive mass of kg/m and comes with predefined numbers of holes nB profiled rail systems and pitch T guide rails for precise installation. It falls under product group ID with an ultra-precise accuracy class UP, ensuring top-tier performance in linear guidance tasks. In summary, the Bosch Rexroth B.GUIDE RAIL CS (R160516932) is an exceptionally precise and robust component suitable for linear guidance systems requiring high degrees of precision and rigidity across various industrial applications.
