BALL RUNNER BLOCK CARBON STEEL KWD-030-SLS-C2-P-1
Manufacturer: Bosch Rexroth
Material #: R162372222
Model : B.RUNNER BLOCK CS KWD-030-SLS-C2-P-1
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-030-SLS-C2-P-1 (R162372222) is a ball runner block designed for precision linear movement and high-load applications. This component is part of the Ball Rail Systems product group, specifically crafted to deliver optimized performance in restricted spaces with its slimline, long, and standard height format (SLS). The runner block body is constructed from unalloyed steel CS, ensuring durability and robustness.
This model boasts an accuracy class P for precision and a preload class C, indicating a medium preload that balances rigidity with smooth motion. It features a ball chain mechanism which contributes to low noise levels and improved travel behavior. The product also includes initial lubrication and preservation to facilitate immediate use upon installation.
The B.RUNNER BLOCK CS KWD-030-SLS-C2-P-1 is equipped with an integrated all-around sealing system that protects against contaminants, thereby extending the product's service life. Additionally, it has an end-face fastening thread for attachments and can be used on all SNS/SNO Ball Guide Rails from Bosch Rexroth. Its dynamic characteristics are enhanced by the optimized entry-zone geometry and a high number of balls which minimize variations in elastic deflection.
This model is self-aligning to compensate for misalignments during operation. It also features a minimum quantity lubrication system with an integrated reservoir for oil lubrication, ensuring long-term maintenance-free operation. The product's high torque load capacity makes it suitable for various demanding applications where precise linear movements are critical.
In terms of technical specifications, the B.RUNNER BLOCK CS KWD-030-SLS-C2-P-1 has an overall length of . mm and can withstand ambient temperatures ranging from min ... max °C for short periods. Its dynamic load capacity C and static longitudinal moment load capacity ML are determined based on DIN ISO standards.
Overall, this ball runner block is engineered to provide reliable performance in sophisticated linear guide systems where precision motion control is essential.
$381.96 USD
More are expected on February 19, 2025
Status: This product is temporarily out of stock.
Qty: Delivered as early as February 19, 2025 when ordered in
