PILLOW BLOCK SEB-F-Z 17

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth PILLOW BLOCK (R159111720) is a high-precision assembly component designed to provide reliable support and alignment for ball screw assemblies. This pillow block unit is part of the SEB-F-Z 17 series and is specifically engineered to cater to demanding linear motion applications. The unit includes a robust steel precision pillow block housing with reference edges on both sides, ensuring accurate installation and alignment. Equipped with an angular contact thrust ball bearing LGN, the pillow block unit offers excellent load handling capabilities. It also features a slotted nut, either NMA or NMZ, and threaded rings GWR for secure attachment and easy adjustment. The design of the pillow block is suitable for screw end forms A, B, C, D, and E, providing flexibility in application across various screw ends. The product has been meticulously crafted to withstand dynamic loads with its dynamic load capacity C and static load capacity C0. These specifications ensure that the pillow block can support axial loads effectively while maintaining stability and performance over time. The size specifications include a nominal size of V, indicating compatibility with specific screw diameters (size d), height (size H), socket width (size SW), tightening torque necessities, as well as other critical dimensions relevant for installation. This Bosch Rexroth pillow block unit is an essential accessory for Rexroth ball screw assemblies, contributing to the overall efficiency and precision of linear motion systems. Its robust construction ensures longevity while its precise engineering guarantees smooth operation in various industrial applications. With a weight of approximately 0.1 kg., it represents an optimal balance between strength and ease of handling during installation or maintenance procedures.
