LINEAR CARRIAGE MKK-065-CR-LCF-XX-TL1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR CARRIAGE MKK-065-CR-LCF-XX-TL1 (R117300763) is a state-of-the-art linear motion system that embodies the latest engineering advancements in compact, ready-to-install guide systems. It is part of the new generation MKXXXXNN series, which maintains backward compatibility while enhancing performance features. This linear module boasts an extremely compact aluminum profile with integrated high-performance Rexroth Ball Rail Systems. The carriage, crafted from aluminum, offers versatility through T-slots or threaded holes for attachments and is designed with centering holes for precise alignment. The unit is driven by a precision Ball Screw Assembly (BASA) in a rolled design available in tolerance grades T5 or T7 according to ISO standards, ensuring zero-clearance and high positioning accuracy. The LINEAR CARRIAGE can accommodate various lubrication versions tailored for connection to one-point lubrication systems, including options like LCF for liquid grease and LCO for oil lubrication. This model includes an integrated measuring system (IMSA), which eliminates the need for external mounting and complex tuning work while preventing inaccuracies due to parallelism offset. The measuring system components are fully integrated into the guide system, allowing individual replacement during servicing. For structural integrity and corrosion resistance, the materials used include anodized aluminum frames and carriages with end blocks (ALST), corrosion-resistant steel with Resist CR coating for ball guide rails and screw assemblies (ALCR), as well as antifriction bearing steel for angular-contact bearings. The LINEAR CARRIAGE is equipped with a comprehensive attachments accessories program that includes sensors, extension cables, clamping fixtures, sliding blocks, connecting shafts, and connection technology suitable for various applications. Additionally, it features an optional screw support SPU that allows high-speed operation over lengths up to 5400 mm while being maintenance-free. Designed to handle high thrust forces with exceptional repeatability and accuracy, this Bosch Rexroth linear carriage system meets the demands of sophisticated linear motion applications without compromising on quality or durability.
