LINEAR CARRIAGE MKR080-ST-LSS-MS-SL1&

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR CARRIAGE MKR080-ST-LSS-MS-SL1 (R117310001) is a state-of-the-art linear motion component designed for precise and high-performance applications. This ready-to-install linear module features an extremely compact aluminum profile with an integrated Bosch Rexroth Ball Rail System, ensuring smooth and accurate movement. The carriage itself is constructed from durable aluminum and comes with T-slots or threaded holes for versatile mounting options, as well as centering holes for precise alignment. This model boasts a precision rolled Ball Screw Assembly with a backlash-free cylindrical single nut, adhering to ISO tolerance grade T7. It supports high speeds over long lengths of up to 5400 mm, while the screw support SPU ensures stability in horizontal applications. The unit is also equipped with an IMSA measuring system fully integrated into the guide system, eliminating inaccuracies due to misalignment and simplifying installation and maintenance processes. Designed with versatility in mind, the MKR080-ST-LSS-MS-SL1 offers various lubrication options including factory initial lubrication (LSS), corrosion prevention without initial lubrication (LPG), preparation for connection to central lubrication systems with liquid grease (LCF), or oil (LCO). The carriage material pairing consists of anodized aluminum for the frame and end blocks, while the Ball Guide Rail, Ball Runner Block, and Ball Screw Assembly are made of antifriction bearing steel with corrosion-resistant coating. Additional features include a comprehensive attachments accessories program that covers sensors, extension cables, switches (proximity or mechanical), clamping fixtures, sliding blocks, connecting shafts, and more. These components allow for seamless integration into various linear motion systems. The LINEAR CARRIAGE MKR080-ST-LSS-MS-SL1 is ideal for applications requiring high positioning accuracy, repeatability, and thrust forces within compact dimensions.
