LINEAR-SET LSADR2-20-WV-500

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSADR2-20-WV-500 (R109852080) is a high-precision linear motion set designed for various applications requiring accurate and smooth linear movement. This product is part of the torque product group and is categorized under the size E series. It features a lightweight precision tandem housing made of aluminum, which offers stability against cocking loads due to its torqueresistant design. The set includes a precision steel shaft with two ball guide grooves and a torqueresistant linear bushing, ensuring reliable guidance and reduced friction. The shaft diameter 'd' is included in the standard length as per the provided table, making it suitable for different installation requirements. This model comes without an external seal, but it is relubricatable, allowing for easy maintenance and extended service life. The bearing plates are made of hardened steel and are set to zero clearance ex works to transmit torque efficiently while maintaining high accuracy. The dynamic load capacity 'C' indicates minimal values as the load direction can be ambiguous; however, this ensures that the system can handle at least the specified loads. The permissible ambient temperature range for this model extends from 'C min' to 'C max', accommodating various working environments. Additionally, it has a maximum permissible linear speed 'vmax' and can withstand a maximum acceleration 'amax', making it suitable for high-speed applications. The outer diameter 'D' corresponds with size E specifications, while the weight of the unit is denoted by ‘m kg/m’. The static load rating 'C' provides insight into its ability to withstand stationary forces, whereas the dynamic torsional moment load capacity 'Mt' reflects its capability to handle twisting forces during operation. Overall, this Bosch Rexroth linear set is engineered for durability and performance in applications where precise linear motion is essential. It combines robust construction with advanced design features to ensure consistent operation under varying conditions.
