LINEAR-SET LSFDR2-20-WV-500

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSFDR2-20-WV-500 (R072352080) is a high-quality linear motion set designed for precision and durability. This linear set features a compact LB flange and a torqueresistant compact linear bushing, ensuring reliable guidance and transfer of forces. It includes a steel flanged sleeve with one ball guide groove for shaft diameters of 20 mm, providing smooth motion and enhanced load-bearing capabilities. The LINEAR-SET LSFDR2-20-WV-500 is built without an external seal, which makes it suitable for applications where seals are not required or could interfere with operation. Its standard steel construction offers robustness, while the bearing plates are torquetransmitting and hardened to ensure zero clearance straight from the factory. Capable of handling dynamic loads with minimal values due to its design that accommodates various loading directions, this linear set can sustain a dynamic load capacity (C) and static load rating (C0) as specified by the manufacturer. It also boasts a dynamic torsional moment load capacity (Mt), ensuring it can withstand rotational forces during operation. This product is designed to be relubricatable, which allows for easy maintenance and longevity of the system. The permissible ambient temperature range for this unit is from -20°C to +80°C, making it versatile for different working environments. Additionally, its maximum permissible linear speed (vmax) and maximum acceleration (amax) specifications ensure that it can perform in high-speed applications without compromising stability or performance. Weighing in at 0.3 kg/m, the LINEAR-SET LSFDR2-20-WV-500 is relatively lightweight yet sturdy enough to resist cocking loads effectively—especially when installing two Linear Sets as per the installation section guidelines provided by Bosch Rexroth. This product falls under Productgroup ID F, indicating its categorization within Bosch Rexroth's range of linear bushings and shafts designed for varied industrial applications requiring precise linear movement.
