LINEAR-SET LSADR1-16-WV-400

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSADR1-16-WV-400 (R109821680) is a highly engineered linear motion set designed for precision applications. This product is comprised of a lightweight precision tandem housing made from aluminum and a precision steel shaft with one ball guide groove, which ensures smooth and accurate linear movement. The torqueresistant linear bushing and hardened steel bearing plates are set to zero clearance by the manufacturer, providing exceptional stability against cocking loads. The LSADR1-16-WV-400 is characterized by its torqueresistant LB ball guide grooves and its ability to transmit torque while maintaining high levels of accuracy. The shaft diameter 'd' comes in a standard length as per the provided table, tailored to fit various applications. Notably, this model is supplied without external seals but remains relubricatable, allowing for maintenance and extended service life. With a dynamic load capacity 'C', this linear set can handle minimal values as the direction of loading may not always be clearly defined. It operates effectively within a permissible ambient temperature range from -20°C to +80°C, ensuring reliable performance in varying environmental conditions. The maximum permissible linear speed 'vmax' and the static load rating 'C' are indicative of the product's robustness in stationary and moving states. Additionally, the LSADR1-16-WV-400 boasts a dynamic torsional moment load capacity 'Mt', highlighting its capability to withstand rotational forces during operation. Its mass 'm' is optimized for efficiency, contributing to the overall performance of the system it's integrated into. This Bosch Rexroth linear set is ideal for applications requiring precise guidance with high torsional rigidity and can be utilized in various fields where reliability and accuracy are paramount. With its well-defined specifications and capabilities, it stands out as an essential component for sophisticated linear motion solutions.
