LINEAR-SET LSHDR1T-16-WV-900

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSHDR1T-16-WV-900 (R072221685) is a high-quality linear motion set designed for precision movements and load-bearing applications. This product comprises two torque-resistant compact linear bushings and a steel shaft with standard length as per the table provided, ensuring robust performance and durability. The shaft diameter is suitable for the sleeve version of the linear set, which is designed without seals for applications where such protection is not critical. Crafted from hardened steel, the bearing plates are torquetransmitting and set to zero clearance ex works, offering exceptional stability against cocking loads. The ball guide grooves are meticulously engineered to accommodate diameter shafts, with one groove for smaller diameters and two grooves for larger diameters. Additionally, a keyway feature facilitates torque transmission effectively. This linear set boasts a dynamic load capacity C that signifies minimal values due to variable loading directions. It operates efficiently within an ambient temperature range of -20°C to +80°C, providing versatility across different working environments. The maximum permissible linear speed vmax ensures swift operation without compromising on precision or stability. The model's mass m/kgm is 0.9, reflecting its lightweight yet sturdy construction that can support substantial loads when both linear bushings are equally loaded. Furthermore, the static load rating C0 and dynamic torsional moment load capacity Mt underscore the product's capability to handle static and dynamic forces adeptly. The Bosch Rexroth LINEAR-SET LSHDR1T-16-WV-900 also features external seals that can be relubricated, extending the lifespan of the components while maintaining smooth operation over time. Whether used in automated production lines or custom machinery, this linear set delivers reliable performance for various linear motion requirements.
