LINEAR-SET LSADR1-12-WV-900

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSADR1-12-WV-900 (R109821285) is a high-quality linear motion system designed for precision applications. This linear set is composed of lightweight, torque-resistant aluminum with a precision steel shaft that includes one ball guide groove. The shaft diameter, designated as size 'd', comes in a standard length as per the provided table and is included with the set. The LSADR1-12-WV-900 is engineered without external seals, making it suitable for environments where such protection is not critical. Its design features tandem housing made from aluminum, contributing to the system's overall light weight while maintaining structural integrity. The hardened steel bearing plates are pre-set to zero clearance by the manufacturer to ensure accurate and smooth motion transfer, enhancing the system's capability to handle torsional loads effectively. This linear set boasts stability against cocking loads and offers relubrication options to maintain optimal performance over time. It operates within a permissible ambient temperature range, ensuring reliable functionality across various working conditions. The maximum permissible linear speed (vmax) and acceleration (amax) specifications attest to its capability to handle dynamic applications. With its dynamic load capacity (C) and static load rating (C), the LSADR1-12-WV-900 ensures minimal values are maintained even when the direction of loading cannot be clearly defined. Additionally, it can handle dynamic torsional moment load capacities (Mt), making it versatile for different types of movements in machinery. Overall, this linear guide type—comprising a linear bushing and shaft—is part of Bosch Rexroth's Series Torque Productgroup ID and is designed for those seeking a reliable solution that combines lightweight construction with robust performance capabilities in their linear motion systems. Its size 'E', outer diameter 'D', size 'H', size 'L', weight specifications, along with its relubricatable feature, make it an adaptable choice for various industrial applications requiring precise linear guidance.
