LINEAR-SET LSSDR2-20-WV-1200
Manufacturer: Bosch Rexroth
Material #: R109652087
Model : LINEAR-SET LSSDR2-20-WV-1200
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSSDR2-20-WV-1200 (R109652087) is a comprehensive linear motion set designed for precision applications requiring high rigidity and resistance to torque. This linear set is composed of a precision steel shaft with a diameter of 20 mm, featuring two ball guide grooves that ensure smooth and precise linear movement. The shaft comes in a standard length of 1200 mm, tailored to fit various application needs without the necessity for additional cutting or customization.
The set includes torqueresistant linear bushings made from hardened steel bearing plates, which have been meticulously adjusted to zero clearance by the manufacturer to provide optimal performance right out of the box. These bushings are capable of withstanding cocking loads, enhancing the system's overall stability and reliability. The absence of external seals in this model suggests that it is intended for use in environments where contamination is not a primary concern.
With its robust construction, the LINEAR-SET LSSDR2-20-WV-1200 can handle dynamic load capacities and torsional moment loads efficiently. The product group ID indicates that it belongs to a series designed for torque transmission applications. It boasts an impressive dynamic load capacity (C) and static load rating (C₀), ensuring durability under varying operational conditions. Additionally, it can operate within a wide range of ambient temperatures from minimum to maximum as specified by the manufacturer.
The outer diameter (D) and size (E) specifications are engineered to meet stringent requirements, guaranteeing compatibility with corresponding components and systems. Maximum permissible linear speed (vmax) and acceleration (amax) figures highlight the unit's capability to perform in high-speed applications without compromising on performance.
Weighing in at an efficient mass-to-length ratio, this linear set offers an ideal balance between weight and structural integrity, making it suitable for a variety of industrial applications where space constraints and weight considerations are critical factors.
$1,020.07 USD
More are expected on March 17, 2025
Status: This product is temporarily out of stock.
Qty: Delivered as early as March 17, 2025 when ordered in
