LINEAR-SET LSSDR1T-25-WV-500

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSSDR1T-25-WV-500 (R109722580) is a comprehensive linear motion set designed for high precision and rigidity in various applications. This product features a steel precision tandem housing, a precision steel shaft with one ball guide groove, and two torque-resistant linear bushings. The linear set is engineered to transmit torque effectively, utilizing hardened steel bearing plates that have been set to zero clearance by the manufacturer, ensuring optimal performance from the outset. The inclusion of external seals adds to the robustness of the system by providing protection against contaminants, which is crucial for maintaining the integrity of the motion set in challenging environments. With its ability to resist cocking loads, this linear set offers exceptional stability, making it suitable for scenarios where precise linear movement is essential. The shaft diameter 'd' and standard length are according to specified tables, offering compatibility with a range of installations. The LINEAR-SET LSSDR1T-25-WV-500 does not come with internal seals as part of its standard version but compensates with other features that ensure reliable operation. Its dynamic load capacity 'C' and static load capacity 'C0' are indicative of its ability to handle both dynamic and static forces efficiently when both linear bushings are under equal load. Additionally, it can endure maximum acceleration 'amax', and operates within a permissible ambient temperature range ensuring its adaptability to varying operational conditions. With a maximum permissible linear speed 'vmax' and an outer diameter 'D', this product demonstrates versatility in speed handling capabilities. The dynamic torsional moment load capacity 'Mt' further exemplifies its strength in applications requiring rotational forces. The LINEAR-SET LSSDR1T-25-WV-500 has a mass 'm kg/m', making it a substantial component capable of supporting significant loads while maintaining precision movement. It falls under the product group ID specific for Bosch Rexroth's high-quality linear sets equipped with tandem format linear bushings for enhanced performance in demanding applications.
