LINEAR-SET LSAO-B-40-DD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSAO-B-40-DD (R103784020) is a high-quality linear motion set designed for applications requiring precise linear guidance and support. This set includes a lightweight precision housing made from aluminum, coupled with a super linear bushing B which lacks a self-alignment feature. The shaft diameter 'd' ensures compatibility with various design requirements, while the inclusion of two external seals provides protection against contaminants, enhancing the longevity of the system. This LINEAR-SET is characterized by its standard version which is secured by a grooved taper pin and offers the capability to be relubricated, ensuring smooth operation over time. The product has been engineered to accommodate maximum acceleration (amax) and can operate within an ambient temperature range of -20°C to 80°C. Its outer diameter 'D' is tailored to ensure fit within specific assemblies. The Bosch Rexroth LINEAR-SET boasts an impressive dynamic load capacity (C), indicating its suitability for handling significant loads in its main direction of operation. It also comes with a static load rating (C) that speaks to its ability to withstand stationary forces without deformation or damage. With breakaway force specifications and maximum permissible linear speeds (vmax), this linear set is capable of achieving speeds up to 5 m/s, although service life may be limited at these higher velocities due to increased wear on plastic components. Tests have demonstrated that this linear set can endure total travel distances ranging from 100 km² to 1000 km² without failure, making it reliable for long-term use in various applications. Its construction also features frictional drags generated by the integrated wiper seals on both sides when not under radial load, which are dependent on speed and lubrication conditions. Weighing in at 0.4 kg, this Bosch Rexroth linear set is ideal for long guides that require shaft support and high levels of rigidity, providing a robust solution for sophisticated linear motion requirements in numerous applications.
