LINEAR-SET LSGF-A-30-DD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSGF-A-30-DD (R108163040) is a high-quality linear set comprised of steel with a flange design, incorporating super linear bushing A with a self-alignment feature. This linear set is specifically designed for precision applications, featuring standard precision flanged housing in lamellar graphite cast iron and an advanced super linear bushing A. The shaft diameter accommodates integration with two seals, enhancing the unit's durability and performance. Equipped with two retaining rings and two additional spacer rings made of steel, this model ensures stability and alignment for shaft diameters. The integrated wiper seals maintain cleanliness within the system, while the radial clearance remains non-adjustable to preserve the integrity of the set. Although it comes without initial lubrication, its design minimizes friction force as noted in its specifications. This LINEAR-SET model has a dynamic load capacity C based on a total travel distance of 100,000 m, which can be adjusted by multiplying by 0.3 when based on 50,000 m travel distance. It boasts an impressive breakaway force and can handle maximum accelerations while operating within an ambient temperature range of -20°C to +80°C. The outer diameter D and size V are meticulously crafted to ensure seamless operation. The static load rating C0 reflects its robustness in stationary conditions. While it offers a maximum permissible linear speed (vmax), service life may be limited due to increased wear on plastic parts at higher speeds; however, tests have indicated reliable performance over significant travel distances without failure. With a weight of 2.7 kg, this product is part of the Linear Set series that's ideal for vertical shaft applications in various engineering designs. Its dynamic load capacity and structural features make it suitable for precise motion control tasks where high reliability and performance are critical.
