R108162040

LINEAR-SET LSGF-A-20-DD

Manufacturer: Bosch Rexroth

Material #: R108162040

Model : LINEAR-SET LSGF-A-20-DD


***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSGF-A-20-DD (R108162040) is a high-precision linear set designed for vertical shaft applications, ensuring smooth and accurate linear motion. This product features a flanged housing made of lamellar graphite cast iron, which includes a super linear bushing A with a self-alignment feature. The bushing is accompanied by two retaining rings and additional spacer rings made of steel, enhancing the rigidity and alignment of the assembly. The shaft diameter 'd' accommodates an integrated wiper seal on both sides to protect against contaminants while maintaining system integrity. This linear set is characterized by its standard precision offering with radial clearance that is not adjustable. It does not require initial lubrication, which simplifies maintenance and reduces downtime for users. The dynamic load capacity 'C' suggests that the unit can handle significant loads during operation, with the ability to multiply its capacity based on travel distance requirements. The Bosch Rexroth LINEAR-SET LSGF-A-20-DD can withstand a maximum acceleration 'amax' and operates efficiently within an ambient temperature range of -20°C to +80°C. Its design ensures minimal friction force 'FR', contributing to a lower breakaway force and enabling higher speeds up to the maximum permissible linear speed 'vmax'. The static load rating 'C0' indicates its capability to endure stationary forces without deformation or damage. Weighing in at 1.7 kg, this linear set comes in size V for series Super A and size E for outer diameter D considerations. Its robust construction promises longevity, with tests indicating a total travel from 100 km² to 1 km² without failure, making it suitable for various industrial applications where precision linear movement is critical.

$117.51 USD

More are expected on March 14, 2025
  Add to Cart

Status: This product is temporarily out of stock.


Qty: Delivered as early as March 14, 2025 when ordered in
