LINEAR-SET LSGF-M-20

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSGF-M-20 (R108112000) is a high-quality linear set designed for precise linear motion applications. This set features a flanged housing made of lamellar graphite cast iron, providing robust support and alignment for the included standard linear bushing with wiper seals. The bushing ensures smooth, clean motion due to its ability to wipe away debris. With a shaft diameter of 20mm and no seal, this Linear-Set offers flexibility in various environments. The radial clearance is not adjustable but has been optimized for this size V unit to achieve similar radial clearance values as specified in the hH column under Radial clearance for the R standard linear bushing. The product is equipped with two retaining rings and two additional spacer rings made of steel, which ensure secure positioning on the shaft. It also features a breakaway force that allows for reliable operation even after periods of static positioning. Designed to withstand a dynamic load capacity C and static load rating C, this unit can handle significant loads while maintaining performance—ideal for applications where load orientation and direction may vary. The permissible ambient temperature range from -20°C to +80°C makes it suitable for diverse working environments. The LINEAR-SET LSGF-M-20 is capable of maximum acceleration and can reach a maximum permissible linear speed vmax, ensuring efficient operation in high-speed applications. Its design also minimizes frictional drags when not under radial load, which are influenced by factors such as speed and lubrication conditions. This product group ID falls within the category of Linear Sets with standard Linear Bushings, flanged type, particularly suited for vertical shaft configurations in modular systems. With its weight carefully considered during design, this Bosch Rexroth Linear Set combines durability with precision engineering to facilitate reliable linear motion solutions.
