LINEAR-SET LSGO-A-20-DD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSGO-A-20-DD (R106762040) is a high-precision linear motion set crafted for applications requiring robust shaft support with superior rigidity. This linear set is composed of steel, featuring an OA-type open design that includes two integrated wiper seals for enhanced protection against contaminants. The set's spheroidal graphite cast iron housing ensures standard precision, while the steel super linear bushing A incorporates a self-alignment feature, providing ease of installation and alignment. With a shaft diameter (d) designed to accommodate substantial loads, the LINEAR-SET LSGO-A-20-DD is secured with a locating screw for added stability. The dynamic load capacity (C) and static load rating (C) are indicative of its ability to handle significant main direction loading, contributing to its suitability for long guides where continuous support is vital. The system can operate within a permissible ambient temperature range from -20°C to +80°C, ensuring reliable performance in various environments. The outer diameter (D), breakaway force, and maximum permissible linear speed (vmax) are engineered to facilitate smooth motion at speeds up to 5 m/s. However, it should be noted that at these maximum speeds, service life may be reduced due to increased wear on plastic components. This model has been tested extensively and has demonstrated an impressive total travel range from 100 million meters to 1 billion meters without failure. Its friction force of 0.3 N highlights its efficiency in motion control applications. Weighing in at just 0.45 kg, the LINEAR-SET LSGO-A-20-DD combines lightweight construction with durable performance. Ideal for use in scenarios where long-term reliability and precision are paramount, this linear set is tailored for demanding applications that require both accuracy and strength in linear guidance systems.
