LINEAR-SET LSG-A-16-DD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSG-A-16-DD (R106561640) is a high-precision linear motion set, designed for seamless integration and superior performance in a variety of applications. This product features a robust steel construction with a closed design, including an advanced super linear bushing A with self-alignment capabilities, ensuring smooth and accurate movement. The precision housing is made from lamellar graphite cast iron for added durability and stability. Equipped with integrated wiper seals on both sides, the LINEAR-SET LSG-A-16-DD effectively protects against contaminants while reducing frictional drag, which varies according to speed and lubrication conditions. The shaft diameter 'd' ensures compatibility with corresponding components, while the outer diameter 'D' facilitates easy installation. This linear set boasts a considerable dynamic load capacity 'C', making it suitable for handling significant loads in its main direction of loading. For non-main loading directions, load capacities can be adjusted using specified factors to ensure optimal performance. The static load rating 'C' further underscores the system's ability to withstand stationary forces without compromising functionality. The LINEAR-SET LSG-A-16-DD operates efficiently within an ambient temperature range of -20°C to +80°C, accommodating various working environments. It also features a maximum permissible linear speed 'vmax', allowing speeds up to 5 m/s under certain conditions. Although higher speeds may limit service life due to increased wear on plastic parts, testing has shown reliable operation over significant travel distances without failure. With a weight of 0.72 kg, this linear guide is easy to handle and install. It represents Bosch Rexroth's commitment to providing high-quality components for precision guides that require straightforward installation processes and fixed working bore diameters for consistent performance in demanding applications.
