SHAFT SUPPORT RAIL WU40-AF2-600

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth SHAFT SUPPORT RAIL WU40-AF2-600 (R105074000) is a high-quality component designed to provide extra rigidity and precision in linear motion applications. This shaft support rail, made from aluminum, features a flange and bore spacing type for easy installation and alignment. It is intended for use with open linear bushings, offering an ideal solution for long guides or high-load scenarios where self-supporting shafts are not viable due to potential shaft warping. The product ensures an optimal pressure angle when paired with the corresponding linear bushing size, which enhances the rigidity of the assembly. The large fastening bolts contribute to this stability, making it suitable for applications that require additional support and precision. The WU40-AF2-600 support rail allows for unlimited length configurations when used with interconnecting shafts, providing versatility in design. This Bosch Rexroth support rail also offers additional degrees of freedom in the circumferential direction compared to profiled guide rails. It's particularly useful in situations where other linear guides may experience warping due to imperfect substructures. The product comes in a standard length as per the table provided by the manufacturer and can be customized to meet specific requirements. The dimensions include Size O thread diameter Mx, Size V, Size t, Size A, Productgroup ID, Size O thread x lead Mx, Size H, Angle, Size E, Bore spacing Type, Length L, Material shaft support rails Aluminum, Shaft diameter d, Size M. This combination creates a robust and precise guiding system when integrated with precision steel shafts. In summary, the Bosch Rexroth SHAFT SUPPORT RAIL WU40-AF2-600 is engineered for durability and precise alignment in demanding linear motion setups where additional support is crucial. It's an integral part of a complete guiding system that ensures smooth operation and longevity of the equipment it is used with.
