SHAFT SUPPORT RAIL WU30-AF2-600

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth SHAFT SUPPORT RAIL WU30-AF2-600 (R105073000) is a high-quality component designed for creating precise and rigid linear guides. This particular model features an aluminum construction with a flange and bore spacing type, providing a durable and stable platform for linear motion applications. The shaft support rail is engineered to work seamlessly with open linear bushings, making it suitable for long guides or high-load scenarios where self-supporting shafts are not viable due to potential shaft warping. This product offers the advantage of unlimited length when utilizing interconnecting shafts, allowing for extensive travel distances without compromising stability. It is specifically tailored to prevent warping that can occur in other linear guides due to imprecise substructures, thus ensuring smooth operation even in demanding situations. The careful adaptation of the support rail to the size of the linear bushing creates an optimal pressure angle for fitting the shaft, which in conjunction with large fastening bolts, contributes to the system's extra rigidity. The Bosch Rexroth SHAFT SUPPORT RAIL WU30-AF2-600 is designed to offer additional degrees of freedom in the circumferential direction compared to profiled guide rails, making it versatile for various requirements. It stands out as a reliable solution for applications where precision and rigidity are paramount. Additional specifications include size O thread diameter Mx, size V, size t, size A, product group ID, size O thread x lead Mx, size H angle, size E bore spacing type, length L material shaft support rails aluminum shaft diameter d size M. This product belongs to a group that filters for precision steel shafts with support rails and is categorized under the linear bushing and shaft guide type. The weight and tolerances are defined according to specific prefix and suffix codes provided by the manufacturer.
