SHAFT SUPPORT RAIL WU12-AF2-600

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth SHAFT SUPPORT RAIL WU12-AF2-600 (R105071200) is a high-quality component designed for creating precise and rigid linear guides. This shaft support rail is ideal for applications that require extra rigidity and stability, particularly where long guides or high loads are present that may cause self-supporting shafts to warp. The product features an aluminum construction with a flange and bore spacing type, ensuring durability and resistance to wear. The WU12-AF2-600 has been carefully engineered to provide the optimal pressure angle when paired with linear bushings, enhancing the fitting of the shaft. Large fastening bolts contribute to the system's overall rigidity. This model is compatible with open linear bushings and can accommodate unlimited lengths by using interconnecting shafts, allowing for versatile configurations tailored to specific application needs. Additionally, this shaft support rail offers extra degrees of freedom in the circumferential direction compared to profiled guide rails, making it suitable for scenarios where other linear guides might experience warping due to imprecise substructures. The product's specifications include various size designations such as thread diameter Mx (Size O), thread x lead Mx (Size V), and bore spacing Type among others, which are essential for ensuring proper fitment and function within a mechanical assembly. The Bosch Rexroth SHAFT SUPPORT RAIL WU12-AF2-600 is part of a product group that includes precision steel shafts with support rails, contributing to its versatility in different industrial applications. Its aluminum material ensures a lightweight yet sturdy solution for supporting linear motion components while maintaining precision across its standard length as per the table provided by Bosch Rexroth.
