SHAFT SUPPORT RAIL WU80-AF1-600

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth SHAFT SUPPORT RAIL WU80-AF1-600 (R105068000) is a precision-engineered component designed to provide robust support and guidance for linear motion applications. This shaft support rail is specifically crafted from aluminum, featuring a flange and bore spacing type that adheres to standard length specifications. The product's design ensures compatibility with open linear bushings, making it suitable for long guides or high-load scenarios where self-supporting shafts are not viable due to potential shaft warping. With the ability to accommodate unlimited lengths through the use of interconnecting shafts, the WU80-AF1-600 offers a versatile solution for various requirements. It provides additional degrees of freedom in the circumferential direction when compared to profiled guide rails, which is particularly beneficial in applications where other linear guides may be prone to warping due to imprecise substructures. The careful adaptation of the support rail to the linear bushing size results in an optimal pressure angle for fitting the shaft. This feature, combined with large fastening bolts, contributes to the product's extra rigidity. The WU80-AF1-600 is part of Bosch Rexroth's product group that includes precision steel shafts with shaft support rails, ensuring high-quality and reliable performance. Key specifications such as size O thread diameter (Mx), size V, size t, angle, size E bore spacing type, length (L), material (aluminum), and shaft diameter (d) are meticulously defined to meet stringent requirements. The weight and tolerances are also specified for precise integration into various systems. This model is ideal for users seeking a durable and accurate linear guide solution capable of supporting substantial loads without compromising on precision or structural integrity.
