SHAFT SUPPORT RAIL WU30-AFH-600

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth SHAFT SUPPORT RAIL WU30-AFH-600 (R105003000) is a high-quality component designed for enhancing the precision and load-bearing capabilities of linear motion systems. This shaft support rail is specifically crafted to work with open linear bushings and is ideal for long guides or applications involving high loads where self-supporting shafts are not feasible due to potential warping. The support rail's construction from aluminum ensures a robust yet lightweight solution, and its flange, high format design allows for additional degrees of freedom in the circumferential direction, offering an advantage over profiled guide rails. The SHAFT SUPPORT RAIL WU30-AFH-600 accommodates unlimited length configurations when used with interconnecting shafts, making it versatile for various installation requirements. Its standard length conforms to the specifications provided in the accompanying table, ensuring compatibility with a wide range of setups. The aluminum material of the shaft support rails not only contributes to the system's overall durability but also aids in maintaining precision across its length. This product is part of Bosch Rexroth's extensive product group ID for linear motion technology and is designed to pair seamlessly with precision steel shafts, enhancing their performance and longevity. The rail's size V, size A, size H, and size M dimensions are meticulously crafted to meet stringent tolerances, guaranteeing reliable operation in demanding applications. Whether it's used in complex machinery or simple linear motion setups, the SHAFT SUPPORT RAIL WU30-AFH-600 provides a solid foundation for any system requiring high levels of accuracy and load capacity.
