LINEAR-SET LSAE-B-40-DD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSAE-B-40-DD (R103684020) is a high-precision linear motion system designed for various applications that require accurate and smooth linear movement. This product features an aluminum housing with a lightweight precision design, incorporating a super linear bushing B without a self-alignment feature for enhanced stability. The system is equipped with external seals and is relubricatable, ensuring long-term durability and ease of maintenance. The LINEAR-SET LSAE-B-40-DD boasts an adjustable design, allowing for zero-clearance or preloaded guides through an adjusting screw used to modify radial clearance. The set comes clamped to the h shaft lower limit, providing immediate use in its optimal state. With a shaft diameter of 40 mm and the inclusion of two integrated wiper seals on each side, it offers reliable protection against contaminants while maintaining low frictional drags even when not under radial load. Key specifications include a standard size V series with no self-alignment feature and a dynamic load capacity denoted as C, indicating its ability to handle loads primarily in the main direction of loading. For loads in other directions, the capacities must be adjusted according to specified factors. The system can operate within an ambient temperature range of -20°C to 80°C and supports maximum acceleration and linear speeds within its designated limits. Additionally, the LINEAR-SET has been tested for total travel distances significantly exceeding standard requirements without failure, demonstrating its robustness for extended use. It comes with a static load rating C for size M and can achieve speeds up to 5 m/s, though higher speeds may reduce service life due to increased wear on plastic parts. Overall, this product group ID encompasses sizes N, E, SW, L, and S with varying capabilities tailored to different application needs while maintaining consistent quality and performance standards expected from Bosch Rexroth linear motion products.
