LINEAR-SET LSAE-B-16-DD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSAE-B-16-DD (R103681620) is a high-precision linear motion component designed for various applications requiring accurate and smooth linear movement. This linear set is constructed from lightweight precision aluminum housing with a super linear bushing B, which lacks a self-alignment feature but offers exceptional guidance accuracy. The shaft diameter 'd' ensures compatibility with corresponding equipment, while the external seals provide protection against contaminants, extending the life of the component. The LINEAR-SET LSAE-B-16-DD is adjustable and relubricatable, allowing for maintenance and fine-tuning to achieve optimal performance. It comes equipped with integrated wiper seals on two sides to minimize frictional drag when not under radial load. The frictional drags are dependent on speed and lubrication conditions. This model has been tested extensively, showing total travel ranging from 100 km to 200 km without failure, ensuring long service life even at maximum permissible speeds of up to 5 m/s. Designed for standard applications where precise linear guidance is necessary, this linear set can handle dynamic load capacities effectively while maintaining low breakaway forces for smooth operation. It can operate within an ambient temperature range of -20°C to +80°C, making it suitable for diverse working environments. The Bosch Rexroth LINEAR-SET LSAE-B-16-DD comes clamped to the h shaft lower limit and is set to zero-clearance by default. For applications requiring zero-clearance or preloaded guides, an adjusting screw enables easy adjustment of radial clearance. Its robust design and versatile capabilities make it an ideal choice for those seeking reliable linear motion solutions in various fields such as automation, machine tooling, and material handling systems. The product's weight stands at 0.3 kg, adding minimal mass to assemblies while providing strong support and guidance capabilities.
