TORQUE RESISTANT BUSHING KBDR1-50-WV-1200

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth TORQUE RESIST.BUSH KBDR1-50-WV-1200 (R069605087) is a high-performance component designed for self-supporting, torsionally stiff guides with a single shaft application. This torqueresistant linear bushing is engineered to provide precise guidance and transfer of torques within mechanical systems. It features a precision steel shaft with one ball guide groove, ensuring reliable torque transmission. The bushing's ball retainer and outer sleeve are constructed from durable PA or POM materials, while the bearing plates are made of hardened steel for enhanced durability and performance. The KBDR1-50-WV-1200 is equipped with balls crafted from rolling bearing steel, offering smooth motion and resistance to wear. An essential part of this bushing system is the hardened steel adjusting screw, which allows for zero-clearance setting, ensuring optimal precision in operation. A robust steel lock nut secures the assembly in place. With a dynamic load capacity C and static load rating C that represent minimal values due to variable direction of loading, this linear bushing system can handle significant stress during use. The dynamic torsional moment load capacity Mt further exemplifies its capability to withstand torsional forces. This product operates effectively within a permissible ambient temperature range and can sustain maximum acceleration amax without compromise. The outer diameter D of the bushing allows for compatibility with various housing sizes, while the maximum permissible linear speed vmax ensures efficient operation at high speeds. Weighing in at . kg/m, it strikes a balance between strength and mass efficiency. Overall, the Bosch Rexroth KBDR1-50-WV-1200 linear bushing is an essential component for applications requiring robust torque resistance and precise linear movement, making it suitable for various mechanical systems that demand high reliability and performance.
