LINEAR-SET LSA-B-20-DD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSA-B-20-DD (R103582020) is a high-precision linear guide designed for applications that require accurate linear movement. This product features a lightweight precision aluminum housing and is equipped with super linear bushing B, which lacks a self-alignment feature, ensuring stable and precise motion. The set includes two external seals that help protect the mechanism from contaminants, enhancing its durability and reliability. With a fixed shaft diameter of 20 mm, the LINEAR-SET LSA-B-20-DD is capable of handling dynamic load capacities efficiently while maintaining a low friction force due to the integrated wiper seals on both sides when not under radial load. The frictional drags are influenced by speed and lubrication conditions. The set is designed to be relubricatable, which aids in maintaining optimal performance over time. The product operates effectively within an ambient temperature range of -20°C to 80°C, making it suitable for various environmental conditions. It has been tested for total travel distances ranging from 100 x 10^6 m to 200 x 10^6 m without failure, indicating its robustness and longevity in service life. The maximum permissible linear speed for this model is up to 5 m/s; however, it's important to note that at these speeds, service life may be limited due to increased wear on plastic parts. This linear set comes in size H with an outer diameter D specified for this size category and includes information on breakaway force and maximum acceleration (amax) capabilities. Its static load rating ensures reliable performance even under sustained loads. Weighing approximately 0.4 kg, the LINEAR-SET LSA-B-20-DD offers an efficient solution for precision guides requiring easy installation with a fixed working bore diameter. Ideal for various applications where precise linear motion is critical, this Bosch Rexroth linear set represents a blend of performance and quality in motion control technology.
