LINEAR-SET LSA-A-10-DD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET (R103561020) is an advanced linear motion system designed for precision applications. This linear set features a lightweight precision housing made of aluminum and incorporates the super linear bushing A with a self-alignment feature, ensuring smooth and accurate movement. The system includes external seals for added protection against contaminants and is relubricatable, extending the service life of the components. The LINEAR-SET LSA-A-10-DD is equipped with a shaft diameter 'd' that comes with two integrated wiper seals on both sides, which contribute to the friction force (FR) when there is no radial load. The frictional drags are dependent on the speed and lubrication conditions. It boasts a high dynamic load capacity (C), which varies based on the direction of loading; factors for adjustment are provided for non-main direction loads. This model has been engineered to handle maximum accelerations (amax) effectively while operating within a permissible ambient temperature range of -20°C to 80°C. The outer diameter 'D' is standardized for size H, which also specifies the breakaway force required to initiate motion. The LINEAR-SET offers impressive maximum permissible linear speeds (vmax), with potential speeds reaching up to 5 m/s, although higher speeds may lead to increased wear on plastic parts. Tests have demonstrated that this Bosch Rexroth linear set can achieve total travel ranging from 100 km² to 10,000 km² without failure, highlighting its robustness and reliability in demanding applications. The static load rating (C0) also ensures stability under stationary loads. With a weight of just 0.3 kg, this product is ideal for applications where lightweight components are essential without compromising performance. The LINEAR-SET LSA-A-10-DD is suitable for various precision guides requiring easy installation and fixed working bore diameters, making it an excellent choice for designers seeking efficient linear motion solutions.
