LINEAR-SET LSATE-A-12-DD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSATE-A-12-DD (R103261220) is a high-quality linear motion system designed for precise and smooth movement in various applications. This system features a lightweight precision tandem housing made from aluminum, which houses two super linear bushings A with self-alignment capabilities, ensuring optimal performance and reliability. The set includes an external reference edge and seals for protection against contaminants, making it suitable for environments where cleanliness is paramount. The linear set is equipped with a shaft diameter d and offers standard relubrication options to extend its service life. It is characterized by its ability to handle dynamic load capacities efficiently when both linear bushings are under equal load, with specific factors provided for non-main direction loadings to ensure accurate capacity calculations. The maximum acceleration (amax) and permissible ambient temperature range demonstrate the robustness of the unit under various operational conditions. With a breakaway force specified for size H, the LINEAR-SET LSATE-A-12-DD ensures low frictional start-up forces, while the maximum permissible linear speed (vmax) indicates its capability to operate at high speeds without significant wear on plastic components. Service life tests have shown impressive travel distances without failure, highlighting the durability of this system. Additionally, this linear set comes clamped to h shaft lower limit and set to zero-clearance, offering immediate precision upon installation. For applications requiring preloaded guides, an adjusting screw allows easy adjustment of radial clearance. The product's weight reflects its lightweight design without compromising strength or performance. This Bosch Rexroth linear set also comes with the option of being configured as a Linear Motion Slide, providing versatility for different application needs. Its dynamic longitudinal moment load capacity and static longitudinal moment load capacity further contribute to its overall robustness and suitability for complex loading scenarios in linear motion tasks.
