TOLERANCE RING AN24X16

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth TOLERANCE RING AN24X16 (R081002401) is a precision-engineered component designed to facilitate secure and stable connections between machine parts with considerable ease and efficiency. This tolerance ring, crafted from carbon steel, exhibits high temperature stability, allowing for continuous operation up to a certain temperature with brief peaks at even higher temperatures. Its design features circumferential flat edges on the outer diameter, making it optimal for use with a standard nominal shaft. The AN24X16 model offers a large tolerance zone which enables it to compensate for differences in thermal expansion between connected elements made of various materials, thereby eliminating the need for keyways or other positive-locking connections. The simplicity of the connecting parts' design contributes to the quick and economical installation process. Additionally, this tolerance ring can withstand various types of chemical stress, ensuring durability and longevity in challenging environments. It is also noted for its capability to transfer torque effectively while supporting permissible radial loads; however, it's important to consult Bosch Rexroth for guidance on values under pulsating and alternating loads. The AN24X16 model maintains its utility across a wide range of applications due to its fixed and secure connection properties. Moreover, special sizes can be requested to meet specific requirements, highlighting the flexibility offered by Bosch Rexroth in accommodating diverse industrial needs. In summary, the Bosch Rexroth TOLERANCE RING AN24X16 is an extremely cost-effective machine element that provides a reliable solution for connecting parts within machinery without compromising on stability or performance under varied thermal and chemical conditions.
