LINEAR-SET LSAHE-H-30-DD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSAHE-H-30-DD (R170223020) is a high-quality linear motion set designed for precise and heavy-duty applications. The set includes an aluminum precision housing and a super linear bushing H, which is engineered to accommodate misalignments of up to 0.5 feet, ensuring smooth operation even in challenging conditions. The shaft diameter 'd' is robust, providing a stable platform for linear movement. This linear set features integrated wiper seals that protect the system from contaminants while also allowing for relubrication to maintain optimal performance over time. The seals contribute to the friction force FR, which varies with speed and lubrication conditions when the bushing is not under radial load. Designed with adjustability in mind, the unit can be secured firmly in place with bolts and has adjustable radial clearance to achieve zero-clearance if required. The LINEAR-SET LSAHE-H-30-DD boasts impressive load capacities that differ based on size and direction of loading, with dynamic load capacity C for size E and static load rating C for size N. It can handle maximum accelerations (amax) efficiently while operating within a permissible ambient temperature range of -20°C to +80°C. The outer diameter D ensures compatibility with various installations, while the breakaway force for size H indicates its initial resistance to motion. Additionally, this model has been designed to sustain maximum permissible linear speeds (vmax), making it suitable for rapid motion tasks. Weighing in at 1 kg, the product offers a balance between strength and ease of handling during installation or maintenance procedures. As part of Bosch Rexroth's product group ID for linear sets with linear bushings, this LINEAR-SET exemplifies reliability and performance in applications requiring precise linear guidance systems.
