TOLERANCE RING AN22X7

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth TOLERANCE RING AN22X7 (R081002201) is a specialized component designed for creating secure, fixed connections between machine parts without the need for keyways or other positive-locking connections. This tolerance ring is part of the Type AN series, featuring circumferential flat edges on the outer diameter that are tailored for use with standard nominal shafts. The ring is crafted from carbon steel, ensuring high temperature stability and resistance to various types of chemical stress. With a nominal size of 22mm in diameter (d) and 7mm in width (b), the AN22X7 tolerance ring is engineered to compensate for differences in thermal expansion between connected elements made from different materials. Its design allows for a large tolerance zone with connecting parts, simplifying the overall design of the components it joins together. This product promises quick and economical installation processes. The Bosch Rexroth AN22X7 boasts an extremely low-cost status as a machine element while maintaining a high degree of reliability and durability. It can continuously operate at temperatures up to certain degrees Celsius, with brief peaks permissible beyond this range. The product's specifications include details on transferable torque and permissible radial load, indicating its ability to handle significant mechanical forces under specific conditions. Special sizes of this tolerance ring can be requested to meet unique application requirements, further demonstrating its versatility across various uses. The weight and additional technical notes are provided to ensure proper usage and installation. This Bosch Rexroth tolerance ring stands out as an effective solution for achieving fixed and secure connections in machinery without complex or costly methods.
