LINEAR-SET LSG-M-60-DD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSG-M-60-DD (R106526000) is a high-quality linear motion set designed for precision applications. This robust assembly features a closed linear bushing and shaft system, ensuring reliable guidance and smooth linear movement. The set is composed of lamellar graphite cast iron steel, providing durability and resistance to wear. The standard precision housing, paired with a standard linear bushing that includes integrated wiper seals, ensures protection against contaminants while maintaining consistent performance. The shaft diameter "d" of the LINEAR-SET LSG-M-60-DD is meticulously crafted to achieve radial clearance values similar to the hH column under Radial clearance for the R standard linear bushing when considering both the outer diameter of the linear bushings and the housing bore. This feature guarantees precise fitment and operational reliability. The two retaining rings included in this set contribute to its structural integrity, ensuring that components remain securely positioned during operation. Additionally, the product can withstand a range of ambient temperatures without compromising functionality or load capacity. Its dynamic load capacity C indicates minimal values as orientation and direction of loading can vary, which also applies to its static load rating C. This linear set is capable of handling maximum acceleration amax and operates efficiently within an ambient temperature range specified in the product details. It has been designed with breakaway force considerations and can sustain maximum permissible linear speeds vmax, making it suitable for various dynamic applications. With a weight specification provided by Bosch Rexroth, users can anticipate how this component will contribute to their overall system mass. Overall, the LINEAR-SET LSG-M-60-DD offers reliable performance for systems requiring precise linear motion control with an emphasis on durability and protection against environmental factors.
