SUPER LINEAR BUSHING KBH-30-D

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth SUPER LINEAR BUSH (R073213040) is a high-precision linear bushing designed to facilitate the movement of heavy loads with maximum accuracy. This closed-type Super H series bushing features a shaft diameter of 30mm and is equipped with a single seal for protection against contaminants. It boasts hardened steel load-bearing plates with meticulously machined ball guide grooves, alongside a machined steel load-bearing plate back, ensuring unparalleled precision. The bushing is capable of compensating for shaft deflection and misalignment, offering a high travel speed to meet demanding applications. The integration of optional double-lipped wiper seals can be selected to enhance protection against debris. The POM ball retainer within the assembly ensures smooth ball circulation, while the balls themselves are crafted from rolling bearing steel for durability and performance. With two metal holding rings securing the configuration, this linear bushing provides multiple rows of balls that contribute to its robust dynamic load capacity. The product can withstand a maximum acceleration and operates effectively within an ambient temperature range of -30°C to +80°C. The SUPER LINEAR BUSH also features low friction coefficients, which vary depending on load conditions but are optimized for heavy loads. Its static load rating is indicative of its ability to handle substantial stationary forces without compromising on performance. Weighing in at just 0.45kg, this Bosch Rexroth linear bushing offers versatility without adding significant weight to the assembly. Its radial clearance specifications are available in various classes (K, H, M), allowing users to select the appropriate fit based on their application requirements. Overall, this model stands out for its ability to deliver smooth linear motion under challenging conditions while maintaining high levels of precision and reliability.
