SUPER LINEAR BUSHING KBH-20

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth SUPER LINEAR BUSH (R073202000) is a high-precision linear bushing designed to facilitate the movement of heavy loads with exceptional accuracy. This Super H series bushing is crafted with a closed configuration and does not include a seal. It features a shaft diameter that can accommodate significant deflection and misalignment, ensuring smooth operation even under challenging conditions. Engineered for durability and performance, the SUPER LINEAR BUSH boasts hardened steel load-bearing plates that contain meticulously machined ball guide grooves. The back of the load-bearing plate is also machined to enhance precision further. This design incorporates more tracks than the Super A series, allowing it to effectively distribute the weight of heavy loads. The bushing's POM ball retainer and balls made from rolling bearing steel are designed to withstand high travel speeds, reaching up to 5 meters per second. For applications requiring additional protection against contaminants, optional integrated double-lipped wiper seals are available. With its robust construction, the SUPER LINEAR BUSH has an impressive dynamic load capacity and static load rating, ensuring reliable performance under the main direction of loading. The ambient temperature range for operation extends from -30°C up to 80°C, making it suitable for various environments. This product comes with two metal holding rings and features multiple rows of balls for enhanced load distribution. Its friction force is minimal under heavy loads due to its efficient design but can vary depending on factors such as speed and lubrication. In summary, the Bosch Rexroth SUPER LINEAR BUSH (R073202000) stands out as an advanced solution for linear motion applications requiring high precision and capacity to support heavy loads while compensating for shaft deflection and misalignment.
