LINEAR-SET LSFDR1-16-WV-400

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSFDR1-16-WV-400 (R072321680) is a high-quality linear motion set designed for precision applications requiring robust guidance and positioning. This linear set is composed of a steel flanged sleeve and a torqueresistant compact linear bushing, equipped with one ball guide groove for diameter shafts up to 16 mm and two ball guide grooves for larger diameter shafts. The product is characterized by its ability to withstand cocking loads, making it suitable for installations where two Linear Sets are used in parallel, as detailed in the installation section of its documentation. The LINEAR-SET LSFDR1-16-WV-400 is crafted without external seals, offering a standard steel version that ensures durability and long service life. Its hardened steel bearing plates are pre-set to zero clearance by the manufacturer, ensuring high precision and reduced play right out of the box. The set can handle dynamic load capacities with minimal values due to variable loading directions, with a static load rating C0 and dynamic torsional moment load capacity Mt provided in its specifications. With a permissible ambient temperature range of -20°C to +80°C, this linear set can operate effectively in various environmental conditions. It also features relubrication capabilities for maintenance ease. The maximum permissible linear speed (vmax) and acceleration (amax) are specified to ensure optimal performance within its mechanical limits. The LINEAR-SET LSFDR1-16-WV-400 weighs 0.3 kg/m and comes in size V from the Bosch Rexroth Series, denoting its compactness and suitability for space-conscious applications. Its dynamic load capacity (C) further illustrates its ability to handle varying operational demands efficiently. Overall, the Bosch Rexroth LINEAR-SET LSFDR1-16-WV-400 is engineered for users seeking a reliable linear motion solution that combines strength, precision, and versatility in various industrial applications.
