TORQUE RESISTANT BUSHING KBDR1-20-WV-1200

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth TORQUE RESIST.BUSH KBDR1-20-WV-1200 (R069602087) is a robust and precision-engineered component designed for self-supporting, torsionally stiff guides with a single shaft. This torque-resistant linear bushing is crafted to provide zero clearance thanks to its adjustable screw that comes pre-set. It features a high-quality precision steel shaft with one ball guide groove, which is essential for transferring torques effectively. The bushing's ball retainer and outer sleeve are constructed from durable materials such as PA or POM, ensuring longevity and consistent performance. The hardened steel bearing plates and rolling bearing steel balls facilitate smooth motion while handling dynamic loads. The unit also includes a hardened steel adjusting screw and a steel lock nut for secure assembly and adjustment. With its standard length conforming to the specified table, the KBDR1-20-WV-1200 is tailored to meet specific customer requirements regarding shaft machining. The product's design emphasizes minimal dynamic load capacity C, which indicates that it can handle significant loads even though the direction of loading may not always be well-defined. It operates efficiently within a permissible ambient temperature range, maintaining performance even under varied conditions. The outer diameter D of the bushing allows for compatibility with various setups, while its maximum permissible linear speed vmax ensures it can keep up with demanding applications. Weighing in at just . kg/m, this linear bushing provides an optimal balance between strength and weight efficiency. Lastly, the static load rating C0 and dynamic torsional moment load capacity Mt highlight its ability to withstand both stationary and rotating forces, making it an excellent choice for applications requiring precise control over movement and torque transmission.
