SUPER LINEAR BUSHING KBB-O-16

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth SUPER LINEAR BUSH (R067301600) is a high-precision linear motion component designed for smooth and accurate linear movement. This particular model, KBB-O-16, is an open type linear bushing without a seal, which makes it suitable for applications where other guides may be prone to warping due to imprecise substructures. It features steel bearing plates with machined ball guide grooves and optimized ball lead-in chamfers that ensure exceptionally smooth travel and a long service life. The SUPER LINEAR BUSH KBB-O-16 is designed without a self-alignment feature, which means it can transfer lower tipping forces along the axial direction. It supports high travel speeds of up to 5 m/s and can handle maximum accelerations while maintaining low friction coefficients between 0.01 and 0.02 under lubrication with oil. The bushing's dynamic load capacity is significant, ensuring that it can withstand the main direction of loading effectively. Constructed with a ball retainer and outer sleeve made of either PA or POM, and balls crafted from rolling bearing steel, this linear bushing promises durability and reliable performance without requiring initial lubrication. It operates within an ambient temperature range of -30°C to +80°C, making it versatile for various environmental conditions. The SUPER LINEAR BUSH has a static load rating C0 that demonstrates its capability to handle static loads efficiently. Its design accommodates shaft diameters (d), facilitating compatibility with fully supported shafts for diverse application needs. The product weighs approximately 0.1 kg and offers various radial clearance options to meet specific requirements. Overall, the Bosch Rexroth SUPER LINEAR BUSH KBB-O-16 is an optimal solution for high requirement applications needing low-cost yet robust linear motion guidance without compromising on performance or longevity.
